NTH-5684 KOYO Bearing

NTH-5684 KOYO Bearing

KOYO BEARING

NEEDLE ROLLER BEARINGS

KOYO NEEDLE ROLLER BEARING

Shaft

Dia.



Dc1



Dc



Dw



Assembly   Designation

Load Ratings

Fatigue

Load Limit

Cu



Speed

Rating(1)

          Dynamic Static
          C Co
in mm

in

mm

in

mm

in

  kN

lbf

kN min-1
11/2 38.15

1.502

75.44

2.970

6.35

0.250

NTH-2448 81.8

18400

280

62900

29.5 5700
2 50.85

2.002

91.31

3.595

9.53

0.375

NTH-3258 129

29000

407

91600

45.7 4700
21/8 54.03

2.127

94.49

3.720

9.53

0.375

NTH-3460 133

30000

433

97400

48.6 4500
21/4 57.20

2.252

97.66

3.845

9.53

0.375

NTH-3662 138

31100

458

103000

51.4 4400
23/8 60.38

2.377

100.84

3.970

9.53

0.375

NTH-3864 143

32100

484.9

109000

54.3 4200
21/2 63.55

2.502

104.01

4.095

9.53

0.375

NTH-4066 147

33000

511

115000

57.1 4100
25/8 66.73

2.627

109.60

4.315

9.53

0.375

NTH-4270 156

35100

556

125000

63.1 3900
23/4 69.98

2.755

112.78

4.440

9.53

0.375

NTH-4472 161

36100

587

132000

66.3 3800
3 76.33

3.005

119.13

4.690

9.53

0.375

NTH-4876 169

38000

641

144000

72.6 3600
31/4 82.68

3.255

125.48

4.940

9.53

0.375

NTH-5280 178

39900

698

157000

78.0 3400
31/2 89.03

3.505

132.26

5.207

9.53

0.375

NTH-5684 180

40500

725

163000

81.1 3200
