SKF Spherical roller bearings 249/1320CAF/W33

Spherical roller bearings
Dealing with very heavy radial and axial loads in applications prone to misalignment or shaft deflections? Meet the challenge with SKF spherical roller bearings, whose high load carrying capacity and ability to accommodate misalignment help you obtain low maintenance costs and long bearing service life. SKF invented this bearing type in 1919 and our range is the widest in the industry today – both open and sealed. Our assortment includes spherical roller bearings designed for many applications, including wind turbine main shafts, continuous casters, vibratory applications and high-speed applications, as well as bearings with Solid Oil, split bearings, SKF ConCentra roller bearing units, and, for the harshest operating environments, our SKF three-barrier solution.

Get A Quote
Contact Us

SKF Spherical roller bearings

Designation Principal dimensions Basic load ratings Speed ratings
dynamic static Reference speed Limiting speed
d[mm]
D[mm]
B[mm]
C[kN]
C0[kN]
[r/min]
[r/min]
  239/1060 CAF/W33   1 060   1 400   250   11 333   26 000   180   360
  239/1060 CAKF/W33   1 060   1 400   250   11 333   26 000   180   360
  240/1060 CAF/W33   1 060   1 500   438   20 724   45 500   150   260
  240/1060 CAK30F/W33   1 060   1 500   438   20 724   45 500   150   260
  241/1060 ECAK30/C3HW33   1 060   1 660   600   31 471   63 000   90   140
  241/1060-2CS6K30/C3HGEA8   1 060   1 660   600   31 471   63 000   20
  249/1060 CAF/W33   1 060   1 400   335   13 354   32 500   160   280
  249/1060 CAK30F/W33   1 060   1 400   335   13 354   32 500   160   280
  BS2-8138-2CS6K30/C4LGEA8   1 100   1 730   660   35 133   71 000   20
  240/1120 BC/CNLVQ7142   1 120   1 580   462   22 936   49 000   20   35
  240/1120 CAF/W33   1 120   1 580   462   22 364   50 000   130   240
  241/1120 ECAK30/C3HW33   1 120   1 750   630   34 016   68 000   85   130
  241/1120-2CS6K30/C3HGEA8   1 120   1 750   630   34 016   68 000   20
  249/1120 CAF/W33   1 120   1 460   335   13 718   34 500   140   260
  238/1180 CAKFA/W20   1 180   1 420   180   6 778   18 600   170   320
  239/1180 CAF/W33   1 180   1 540   272   13 076   31 000   150   300
  239/1180 CAKF/W33   1 180   1 540   272   13 076   31 000   150   300
  241/1180 ECAK30/C3HW33   1 180   1 850   670   38 266   78 000   75   110
  241/1180-2CS6K30/C3HGEA8   1 180   1 850   670   38 266   78 000   20
  249/1180 CAF/W33   1 180   1 540   355   15 751   40 500   130   240
  230/1250 CAF/W33   1 250   1 750   375   21 256   45 000   130   240
  230/1250 CAKF/W33   1 250   1 750   375   21 256   45 000   130   240
  241/1250 ECAK30/C3HW33   1 250   1 950   710   40 892   88 000   70   100
  241/1250-2CS6K30/C3HGEA8   1 250   1 950   710   40 892   88 000   20
  249/1250 CAF/W33X   1 250   1 630   375   18 114   46 500   120   220
  249/1320 CAF/W33   1 320   1 720   400   18 714   49 000   110   200
  249/1320 CAK30F/W33   1 320   1 720   400   18 714   49 000   110   200
  248/1500 CAK30FA/W20   1 500   1 820   315   14 684   45 000   110   220
  248/1800 CAK30FA/W20   1 800   2 180   375   20 274   63 000   75   140
